Technical parameter
1.Frame size:H56-355;
2.Power:0.12-355Kw;
3.Voltage:220-660V;
4. Rated Frequency: 50 Hz / 60 Hz;
5. Poles: 2 / 4 / 6
6. Speed: 960 -2980 r/min
7. Ambient Temperature: -15°C-40°C
8. Model of CONEECTION: Y-Connection for 3 KW motor or less while Delta-Connection for 4 KW motor or more;
9. Mounting: B3; B35; B34; B14; B5; V1;
10. Current: 1.5-50 A (AC);
11. Duty: continuous (S1);
12. Insulation Class: B;
13. Protection Class: IP44;
14.Frame material: aluminium body/cast iron
15. Cooling Method: IC411 Standards;
16. Altitude: No more than 1,000 meters above sea level;

Technical Datas
